iDisplays is an established specialist supplier of displays and embedded solutions for industrial and military users worldwide. In conjunction with our technical sales team, our in-house support team will help you to optimise your designs and thereby achieve its maximum potential. it is our aim to provide you with a quality product best suited to meet the rigorous demands of your particular application.
| Processor | Intel® Core™ i7−4700EQ, 4×2.4 GHz |
|---|---|
| Memory | up to 8GB |
| Storage | SSD 2x256GB minimum |
| Display | Full HD 15.6″ 1920×1080 EMI/RFI shielded |
| Interfaces | USB – 4,RS232/422 – 4,ethernet – 1,LPT – 1,microphone – 1,audio (stereo) – 1,HDMI – 1,SVGA – 1 |
| Video | Radeon E6760 1 Gb RAM |
| CD R/CD RW/DVD R/DVD RW | slot type – 1 |
| Camera | 2MP |
| Power supply | built in battery,external 12-32VDC |
| Power consumption | 200W with heater |
| Battery operation | built in – 5 hours,external – 5 hours |
| Outline dimensions, mm | 400/350/90 |
| Weight, Kg | 9.0 |
| Operating temperature | -20C + 60C – battery operation,-40C + 60C – external power supply |
| Humidity | 100%, 35ºС, 60-107kPa |
| Survival temperatures | will restore functionality after being subjected to:-65C,+70C |
| Vibration | 4g, 1-80 Hz |
| Shock, multiple | 15g, 5-10ms |
| Shock, single | 100g, 1-5ms |
| Rain intensity | 5mm/min |
| Static Dust / Sand | 2gr/m3 at air flow 0.5 – 1m/s |
