Industrial Displays

IDISDPLAYS is specialised in the design and manufacture of Industrial Displays for use in demanding industrial environments.

IDISPLAYS offer series of LCD-TFT modules with screen sizes ranging from 3.5" to 65".

With the ability to custom build Industrial displays according to precise specifications, IDISPLAYS has the solution for any LCD display needs. If you are looking for LCD displays in rack mount , Panel mount, desktop or console mount configurations, with other available enhancements including touch screen, dimmer function, colour and finish, they are all offered with IDisplays.

Our in-house Brightness enhancement technology has been created to make our displays sun readable and ideal for outdoor signage and public information displays.

Why Choose Displays ?

  • The latest technology adopted in the product
  • Price advantage for OEM / ODM
  • Designed for continuous operations with minimum failure rates
  • Built with Industrial grade screened components
  • Built to customer specifications with model numbers and software customisation
  • One year replacement warranty
Model No ID-065 ID-104 ID-121 ID-150 ID-190 ID-210 ID-240
Screen Size 6.5 Inch 10.4 Inch 12.1 Inch 15 inch 19 inch 21 inch 24 inch
Resolution 1024 x768 1024 x768 1024 x768 1024x768
1600x1200
1280 x1024 1600 x1200 1600 x1200
Aspect ratio
4:3
Brightness
450 Nits 600 Nits 500 Nits 600 Nits 650 Nits 1200 Nits 1000 Nits
Contrast ratio 800:1 800:1 500 Nits 600 Nits
Backlight
LED WITH 100000 HRS MTBF
Colors
262K/16.7M
View angle
80/80/80/80 (Typ.)(CR≥10)
Environment
Operating Temperature: -10 ~ 70 °C ; Storage Temperature: -30 ~ 80 °C ; Vibration Level: 2.0G (19.6 m/s²)
Mounting Type
Rack mount / Panel Mount / Console mount
Touch Screen
Resistive / capacitive / IR Type ( optional for all the models)

NOTE : If you are not able to find the display size that you are looking for in our website please contact us and we will built it for you without any NRE charges and MOQ terms
